Teco Westinghouse: Stainless Steel Washdown
January 19, 2021
Stainless Steel Washdown motors are specifically designed for the rugged and demanding environments required for Car Wash, Food Processing, and other Washdown applications.
Features
- – 1/2-10HP
- – Totally Enclosed Fan Cooled IP66 Design
- – 60Hz, 230/460V or 575V
- – Horizontal F1 Mount
- – 3600 & 1800 RPM
- – NEMA Premium Efficiency
- – 1.15 S.F.
- – Class B Temperature Rise
- – Continuous Duty
- – 40°C Ambient
- – Class F Insulation
- – NEMA Design B Torques
- – Stainless Steel Frame, End Brackets and Hardware
- – Grounding Terminal Inside Main Conduit Box
- – Stainless Steel Oversized Main Conduit Box – F3 Mounted (IM1001)
- – Designed for 3300 ft. Elevation
- – Bi-Directional Rotation
- – SUS304 Stainless Steel Shaft
- – Double Shielded Bearings Pre-Packed with MULTEMP SRL
- – Contact Lip Type Seal on Both Ends
- – Etched Nameplate on the Stainless Steel Frame
- – New Dual Column Design Nameplate as Standard (60/50 Hz)
- – Aluminum Die Cast Squirrel Cage Rotor Construction
- – Suitable for Inverter Use per NEMA MG-1.4.4.2, Part 31
- – Inverter Duty Speed Range: 10:1 Variable Torque, 4:1 Constant Torque
- – 9 Leads
- – Two Drain Holes on Bottom of Frame and one in the C-Flange
- – Motors are U.L. Recognized, CSA Approved and CE Marked
- – Department of Energy Efficiency Certificate # CC082A
- – Encapsulated Windings as Option
