Improved Belt Alignment Tool from Easy-Laser Allows Measurement up to 10 Meters

March 2, 2023

The Easy-Laser® D92 BTA launched as an easy-to-use tool for alignment of belt transmissions.

Updated Laser Alignment Tool

Easy-Laser

The D92 is an upgraded version of our bestseller, the D90, that has been a part of our product range for many years. The new unit has two power levels (high/low) which makes it possible to measure over much longer distances than before, up to 10 m.

Just as before, it fits both small and large belt sheaves/pulleys and is easily attached with magnets. It is attached to the side of the sheave/pulley and not to the belt groove. This means it is just as easy to adjust v-belt, flat belt and timing belt pulleys as chain wheels.

Quick, Easy, and Accurate!

The alignment procedure is very straightforward. Once the measuring equipment is mounted, the laser beam is projected onto the targets, which are read “visually”. When the laser hits the target slots, the machine is in the right position. This procedure can be performed by a single operator.

Source
